Oblique Transform Plug-in
Open beta version of our plug-in. Upon installation adds the following commands:
!_ObliqueElevation
Transforms selected objects to be viewed oblique projection from Front viewport
!_ObliquePlan
Transforms selected objects to be viewed oblique projection from Top viewport
!_ObliqueRestoration
Transforms all oblique objects to original 3D form
To learn how to make effective use of this plug-in, check out this tutorial:
Installation
1. Locate ObliqueTransform_Installer.rhi file, run the file, and follow instruction
2. To install toolbar, open rhino options, and navigate to toolbars tab
3. Choose file > Open, and locate ObliqueTransform_Toolbar.rui file
4. If the commands don't appear or auto-complete on your command line, try running EditPythonScript and close the popup window.
